Atlas, the world’s first Smart Lane Machine, will transform the relationship between machine owners and their lane machines forever. The subtle allure of the Atlas Lane Machine is a tremendous contrast to the power that lives inside.

A small custom-built control board, carefully constructed and adapted specifically for lane machines, opened the door for these machines to join Kegel’s budding Smart Ecosystem.

The one-of-a-kind Smart Lane Machine Operating System has broken the mold to achieve never-before-seen functionality, communicating seamlessly with an array of Kegel systems.

The simplicity, mechanical improvements, and new user interface leverage these newfound capabilities, allowing the user an experience beyond compare.

Atlas has arrived and this is only the beginning.

SMART FEATURES

• Kegel Smart ID User Integration
• Compatible with Smart Link Desktop Application
• Remote access for technicians to view diagnostic information
• Automatic software updates (optional)
• Powered by Kegel Cloud Servers
• Onboard backups
• Full detailed error messages per lane
• Automatic end distance settings
• Real-time automatic speed adjustments
• Enhanced lane-skipping capability
• LED Error Indication System

PATTERN MANAGEMENT

• Onboard access to Kegel's Pattern Library
• Ability to send patterns from Kegel Pattern Library Mobile App to machine
• 30 patterns stored in memory
• Unlimited pattern sessions
• Upgraded 7-Day Planner & Pattern Designer
• Encoder-managed oil head for increased precision
• Improved Pattern Report
• Automatic burn pair

CONDITIONING

• High-speed ethernet-controlled driver for more accurate oil application
• Sanction Technology™ fluid metering conditioning system
• Conditioner float switches with low-level warning message
• Computer-controlled variable mic oil pumps
• Computer-controlled oil pump calibration
• DUO transfer system (roller and single transfer brush)
• Board-to-board pattern control
• Pattern verification capability

SPECIAL FEATURES

• Extruded aluminum cleaner and oil bar
• Proprietary designed relay board
• Integrated Wi-Fi
• 2 lithium battery options based on number of lanes conditioned per day
• Chassis style pc plate (centerplate) with minimal exposed wires/connections for a simplified inside look
• Tank light

COMPONENTS / OPERATING SYSTEM

• Custom Control Board with simplified wiring
• Industrial Controller
• Kegel Smart Lane Machine Operating System
• Simple embedded inputs and outputs
• Split input system for faster processing
• Remappable outputs and inputs
• Complete relay isolation (single-function)
• New user interface for enhanced user experience and machine functionality
• 10” full color HD touchscreen display
• Zero-latency, super responsive touchscreen
• Test input/output menu option

CLEANING

• Easy to remove vacuum motor
• Sprayless cleaning system
• Cleaner float switches with low-level warning message
• Large waste recovery tank (50+ lanes before emptying)
• Patented cushion roller wrap for better cleaning
• Squeegee cartridge for easy replacement of blades
• Multi-adjustment squeegee assembly

DRIVE

• Omni Wheel for better lane-to-lane transitions
• Auto-aligning lane whiskers
• Smoother whisker reaction controlled by OS
• Zero Turn Radius lane-to-lane walking function
• Independent drive motors and control for easy motor balancing using the user interface
• Front safety object detection
• Universal speed controls
• Patented six variable drive speeds
• Backend adjustable cleaning speed
